Screw on System A\ SCLCR/L SCLCR/L 0D Min machining Dia \ 95/ 95 ° n * s* i S O i L L J •R type insert _ •R type insert Stock Size Stock Size Designation Inserts Designation Inserts R L 0Dmin 0d H L i S a Screw Wrench R L 0Dmin 0d H L l S a Screw Wrench S0510J-SCLCR/L03 6 10 9 110 15 3 15° ccnno3oinn M1.6x3 T-6 S07K -SCLCR/L06 8 8 7 125 18 5 15° S0610J-SCLCR/L03 7 10 9 110 15 3 15° S08K -SCLCR/L06 9 8 7 125 18 5.5 13° M2.5X5 CCnn0602DD T-8 S0610J-SCLCR/L04 7 10 9 110 15 3.5 13° ccnno4oinn M2.0x4 T-6 S10K -SCLCR/L06 11 10 9 125 22 7 12° S0612K-SCLCR/L04 7 12 11 125 18 3.5 13° S12M-SCLCR/L06 13 12 11 150 25 8 10° M2.5X6 S0812K-SCLCR/L06 10 12 11 125 24 5 13° S12M-SCLCR/L09 16 14 13 150 27 5.5 10° S0616M-SCLCR/L06 7 16 11 150 18 3.5 12° S14Q-SCLCR/L09 15 12 11 180 27 8 12° S1016M-SCLCR/L06 13 16 15 150 30 6 12° CCnn0602DD M2.5X6 T-8 S16Q-SCLCR/L09 17 16 15 180 34 11 10° ccnno9T3nn M3.5X9 T-15 S1216M-SCLCR/L06 16 16 15 150 36 7 10° S20Q-SCLCR/L09 21 20 18 180 38 13 8° S1020M-SCLCR/L06 13 20 18 150 30 6 8° S25R - SCLCR/ L09 26 25 23 200 45 17 6° S1220M-SCLCR/L06 16 20 18 150 36 7 8° S32S-SCLCR/L09 33 32 30 250 45 22 4° S1220M-SCLCR/L09 16 20 18 150 36 7.5 8° ccnno9T3nn M3.5X9 T-15 S20Q-SCLCR/L12 21 20 18 180 42 13 8° S25R-SCLCR/L12 26 25 23 200 45 17 8° ccnni204nn M 5.0X12 T-20 S32S-SCLCR/L12 33 32 30 250 45 22 6° S40T-SCLCR/L12 41 40 38 300 48 27 4° 243 244
