SEC-External Holders SDJC Type SEC-SD Type Profiling Tool Holder - General Turning , Facing and Profiling 93° Screw-on SDJC Fig 1 External / Profiling / Facing WF B External Holders 93° 0˚ HBKL LF 0˚ HF C H Figure shows right-hand (R) tool. Holder Parts  Dimensions (mm) Neg. Stock Overall Cutting Cutting Edge Applicable Insert Flat Screw Wrench Height Width Head Length Edge Height Cat. No. Previous Cat. No. Ref. Fig R L Cat. No. Nm H B LF WF HF HBKL Page (For Torx Holes) SDJC R/L0808H07 SDJC R/L0808-07 ● 8 8 100 10 8 15 B85 1 Pos. DC□□0702 on BFTX02506N 1.5 TRX08 SDJC R/L1010H07 SDJC R/L1010-07 ● ● 10 10 100 12 10 18 1 SDJC R/L1212H11 SDJC R/L1212-11 ● ● 12 12 100 16 12 18 1 SDJC R/L1616H11 SDJC R/L1616-11 ● ● 16 16 100 20 16 18 B88 1 DC□□11T3 on BFTX0409N 3.4 TRX15 SDJC R/L2020K11 SDJC R/L2020-11 ● ● 20 20 125 24 20 18 1 SDJC R/L2525M11 SDJC R/L2525M11 ● ● 25 25 150 29 25 18 1 C D R S T V W Special Applicable Inserts SDJC Type Name of ● Refer as well to the Insert Selection Guide (page A10 on). Chipbreaker / GU Legend 1st Recommended Insert CBN / PCD Photo ● Some combinations need to be made to order or cannot be manufactured. Grade AC8025P Cutting Range P (Steel) M (Stainless Steel) K (Cast Iron) S (Exotic Alloy) N (Non-ferrous) H (Hardened Steel) Hard Brittle Material Process Finishing Medium Cutting Roughing Finishing Medium Cutting Roughing High-speed Finishing Finishing to Medium Cutting Medium to Roughing Finishing to Medium Cutting High-precision/Finishing Finishing to Medium Cutting Coated Uncoated Q General FB SU MU LB SU MU SUMIBORON MU No Chipbreaker FX SUMIDIA AG SUMIBORON SUMIBORON SUMIDIA Cutting T1500Z AC8025P AC8025P AC6030M AC6030M AC6030M BN7000/BNC500 AC4015K AC4015K AC5015S DA1000 H1 BNC2020 BN2000 DA90 High FC SI SC FC SI SC SUMIBORON SI SUMIDIA SUMIBORON SUMIBORON SUMIDIA Binderless Precision Q Q Q T1500A AC1030U AC1030U AC1030U AC1030U AC1030U BN7000/BNC500 AC5015S DA1000 BNC2010 BN1000 NPD10 Recommended Cutting Conditions A10 on A14 on A16 on A18 on A22 on A20 on M2 on BNC500 is for ductile cast iron. N m Recommended Tightening Torque (N·m) C15
