FRACTIONAL & METRIC 4 Flute High Shear 30° POS 4 LF APMX 54 TOLERANCES (inch)DCDCONDC= +0.0000/–0.0020 FRACTIONAL SERIES DCON = h6 inch EDP NO. CUTTING LENGTH OVERALL SHANK UNCOATED Ti-NAMITE-C DIAMETER OF CUT LENGTH DIAMETER (TiCN) DC APMX LF DCON 1/16 3/16 1-1/2 1/8 35473 35500 3/32 3/8 1-1/2 1/8 35475 35501 1/8 7/16 1-1/2 1/8 35477 35502 NON-FERROUS 5/32 9/16 2 3/16 35478 35503 PLASTICS/COMPOSITES 3/16 9/16 2 3/16 35479 35504 7/32 5/8 2-1/2 1/4 35480 35505 For patent 1/4 3/4 2-1/2 1/4 35481 35506 information visitwww.ksptpatents.com 9/32 3/4 2-1/2 5/16 35482 35507 5/16 13/16 2-1/2 5/16 35483 35508 3/8 7/8 2-1/2 3/8 35485 35509 7/16 1 2-3/4 7/16 35487 35510 1/2 1 3 1/2 35489 35511 9/16 1-1/8 3-1/2 9/16 35491 35512 5/8 1-1/4 3-1/2 5/8 35493 35513 3/4 1-1/2 4 3/4 35495 35514 1 1-1/2 4 1 35497 35515 LF APMX TOLERANCES (mm) 54M DC = +0,000/–0,050DCDCONDCON = h6 METRIC SERIES RE = +0,000/–0,025 mm EDP NO. CUTTING LENGTH OVERALL SHANK UNCOATED Ti-NAMITE-C DIAMETER OF CUT LENGTH DIAMETER (TiCN) DC APMX LF DCON 3,0 8,0 38,0 3,0 45477 45478 3,5 10,0 57,0 6,0 45479 45480 NON-FERROUS 4,0 11,0 57,0 6,0 45481 45482 PLASTICS/COMPOSITES 4,5 11,0 57,0 6,0 45483 45484 5,0 13,0 57,0 6,0 45485 45486 For patent 6,0 13,0 57,0 6,0 45487 45488 information visitwww.ksptpatents.com 8,0 19,0 63,0 8,0 45489 45490 10,0 22,0 72,0 10,0 45491 45492 12,0 26,0 83,0 12,0 45493 45494 14,0 26,0 83,0 14,0 45495 45496 16,0 32,0 92,0 16,0 45497 45498 20,0 38,0 104,0 20,0 45499 45500 206 END MILLS wwENwD.kMyIoLcLSera-sgstool.com
