METRIC 4 Flute End Mills POS 4 TOLERANCES (mm) 1M • 1XLM  D1 = +0,000/– 0,050 D2 = h6 METRIC SERIES mm EDP NO. SERIES CUTTING LENGTH OVERALL SHANK UNCOATED Ti-NAMITE Ti-NAMITE-C Ti-NAMITE-A DIAMETER OF CUT LENGTH DIAMETER (TiN) (TiCN) (AlTiN) D1 L2 L1 D2 1,0 4,0 38,0 3,0 40105 48500 48522 48543 1M 1,5 4,5 38,0 3,0 40109 48501 48523 48544 1M 2,0 6,3 38,0 3,0 40113 48502 48524 48545 1M 2,5 9,5 38,0 3,0 40117 48503 48525 48546 1M STEELS 3,0 12,0 38,0 3,0 40121 48504 48526 48547 1M 3,0 25,0 75,0 3,0 43101 49388 49401 49414 1XLM STAINLESS STEELS 3,5 12,0 50,0 4,0 40125 48505 48527 48548 1M CAST IRON 4,0 14,0 50,0 4,0 40129 48506 48528 48549 1M HIGH TEMP ALLOYS 4,0 25,0 75,0 4,0 43103 49389 49402 49415 1XLM 4,5 16,0 50,0 6,0 40133 48507 48529 48550 1M TITANIUM 5,0 16,0 50,0 6,0 40137 48508 48530 48551 1M HARDENED STEELS 5,0 25,0 75,0 5,0 43107 49391 49404 49417 1XLM NON-FERROUS 6,0 19,0 50,0 6,0 40141 48509 48531 48552 1M PLASTICS/COMPOSITES 6,0 25,0 75,0 6,0 43105 49390 49403 49416 1XLM 7,0 19,0 63,0 8,0 40145 48510 48532 48553 1M For patent 8,0 20,0 63,0 8,0 40149 48511 48533 48554 1M information visit 8,0 25,0 75,0 8,0 43115 49392 49405 49418 1XLM www.ksptpatents.com 9,0 22,0 75,0 10,0 40153 48512 48534 48555 1M 10,0 22,0 75,0 10,0 40157 48513 48535 48556 1M 10,0 38,0 100,0 10,0 43125 49393 49406 49419 1XLM 11,0 25,0 75,0 12,0 40161 48514 48536 48557 1M 12,0 25,0 75,0 12,0 41665 48515 48537 48558 1M 12,0 50,0 100,0 12,0 43135 49394 49407 49420 1XLM 12,0 75,0 150,0 12,0 43145 49395 49408 49421 1XLM 14,0 32,0 89,0 14,0 40169 48516 48538 48559 1M 14,0 75,0 150,0 14,0 43155 49396 49409 49422 1XLM 16,0 32,0 89,0 16,0 40173 48517 48539 48560 1M 16,0 75,0 150,0 16,0 43165 49397 49410 49423 1XLM 18,0 38,0 100,0 18,0 40177 48518 48540 48561 1M 18,0 75,0 150,0 18,0 43175 49398 49411 49424 1XLM 20,0 38,0 100,0 20,0 40181 48519 48541 48562 1M 20,0 75,0 150,0 20,0 43185 49399 49412 49425 1XLM 25,0 38,0 100,0 25,0 40185 48520 48542 48563 1M 25,0 75,0 150,0 25,0 43195 49400 49413 49426 1XLM www.kyocerEaN-DsgMstILoLoSl.com END MILLS 219
