ICe-Carb сверла с внутренней подачей СОЖ RH 140 5xD ДОПУСКИ (мм) ТЕХНИЧЕСКАЯ EDP NO. ≤3 ДИАМЕТР ИНФОРМАЦИЯ 102 ПРЕДВАРИТЕЛЬНОЕ ДИАМЕТР ОБЩАЯ ДЛИНА ДЛИНА ДЛИНА Ti-NAMITE-A D1 = +0,002/+0,012 ДИАМЕТР ОТВЕРСТИЕ ХВОСТОВИКА ДЛИНА ЗУБЬЕВ РАБОЧЕЙ ХВОСТОВ (AlTiN) D2 = h6 ПОД РЕЗЬБУ ЧАСТИ D1 D2 L1 L2 L3 L4 >3–6 ДИАМЕТР 3,0 6,0 66,0 28,0 23,0 36,0 63901 D1 = +0,004/+0,016 3,1 6,0 66,0 28,0 23,0 36,0 63902 D2 = h6 3,2 M3,5 X 0,35 6,0 66,0 28,0 23,0 36,0 63903 >6–10 ДИАМЕТР СТАЛЬ 3,3 M4 X 0,7 6,0 66,0 28,0 23,0 36,0 63904 D1 = +0,006/+0,021 НЕРЖАВЕЮЩАЯ СТАЛЬ 3,4 6,0 66,0 28,0 23,0 36,0 63905 D2 = h6 ЧУГУН 3,5 M4 X 0,5 6,0 66,0 28,0 23,0 36,0 63906 >10–18 ДИАМЕТР ЖАРОПРОЧНЫЕ СПЛАВЫ 3,6 M4 X 0,35 6,0 66,0 28,0 23,0 36,0 63907 D1 = +0,007/+0,025 3,7 M4,5 X 0,75 6,0 66,0 28,0 23,0 36,0 63908 D2 = h6 ТИТАН 3,8 10-24 6,0 74,0 36,0 29,0 36,0 51904 >18–30 ДИАМЕТР ЗАКАЛЕННАЯ СТАЛЬ 3,9 6,0 74,0 36,0 29,0 36,0 63909 D1 = +0,008/+0,029 4,0 M4,5 X 0,5 6,0 74,0 36,0 29,0 36,0 63910 D2 = h6 4,1 6,0 74,0 36,0 29,0 36,0 63911 4,2 M5 / M5 x 0,75 6,0 74,0 36,0 29,0 36,0 63912 4,3 6,0 74,0 36,0 29,0 36,0 63913 4,4 12-24 6,0 74,0 36,0 29,0 36,0 63914 4,5 M5 X 0,5 6,0 74,0 36,0 29,0 36,0 63915 4,6 12-28,0 6,0 74,0 36,0 29,0 36,0 63916 4,7 12-32 6,0 74,0 36,0 29,0 36,0 63917 4,8 7/32-32 6,0 82,0 44,0 35,0 36,0 63918 4,9 6,0 82,0 44,0 35,0 36,0 63919 5,0 M6 X 1 6,0 82,0 44,0 35,0 36,0 63920 5,1 1/4-20 6,0 82,0 44,0 35,0 36,0 63900 5,2 M6 X 0,75 6,0 82,0 44,0 35,0 36,0 63921 5,3 6,0 82,0 44,0 35,0 36,0 63922 5,4 6,0 82,0 44,0 35,0 36,0 63998 5,5 M6 X 0,5 6,0 82,0 44,0 35,0 36,0 63923 5,6 6,0 82,0 44,0 35,0 36,0 63924 5,7 6,0 82,0 44,0 35,0 36,0 63925 5,8 6,0 82,0 44,0 35,0 36,0 63926 5,9 6,0 82,0 44,0 35,0 36,0 63927 6,0 M7 X 1 6,0 82,0 44,0 35,0 36,0 63928,0 6,1 8,0 91,0 53,0 43,0 36,0 63929 продолжение на след. стр. 92 www.sgstool.com www.haltec.ru
