G2 - General purpose - Square CUTTING PARAMETERS INFO G2210-G2211 Material GroupISO 513 P1 P2 K1 P3 P4 P7 M1 K2 P5 M2 K3 N1 N2 N3 N4 Hardness/Rm ≤700 N/mm² 600÷1000 N/mm² ≤35 HRC ap x ae 0.5D x D 0.5D x D 0.5D x D 0.5D x D Vc (m/min) 70÷90 45÷65 30÷50 80÷120 D fz(mm)(mm/z) fz(mm/z) fz(mm/z) fz(mm/z) CARBIDEDRILLS SLOTTING 2 0.007 0.006 0.005 0.009 PU-HPU 3 0.010 0.009 0.008 0.013 TA-4HTA 4 0.014 0.012 0.011 0.018 SUH 5 0.018 0.015 0.014 0.023 ALH 6 0.023 0.019 0.017 0.029 HRC 8 0.030 0.026 0.023 0.039 SUH MINI 10 0.035 0.030 0.026 0.046 HL 12 0.041 0.035 0.031 0.053 HSD < D3 mm: ap = 0.2D C-SD-TA Material Group P1 P2 K1 P3 P4 P7 M1 K2 P5 M2 K3 N1 N2 N3 N4 ISO 513 Hardness/Rm ≤700 N/mm² 600÷1000 N/mm² ≤35 HRC ap x ae 1.5D x 0.5D 1.5D x 0.5D 1.5D x 0.5D 1.5D x 0.5D Vc (m/min) 70÷90 45÷65 30÷50 80÷120 D fz fz fz fz (mm) (mm/z) (mm/z) (mm/z) (mm/z) HSS SIDE MILLING 2 0.008 0.007 0.006 0.011 DRILLS 3 0.012 0.010 0.009 0.016 4 0.017 0.014 0.013 0.022 LFTA 5 0.022 0.018 0.016 0.028 SUTAHSS-HSS/CO 6 0.027 0.023 0.020 0.035 8 0.036 0.031 0.027 0.047 10 0.042 0.036 0.032 0.055 12 0.049 0.042 0.037 0.064 < D3 mm: ae = 0.2D Material Group P1 P2 K1 P3 P4 P7 M1 K2 P5 M2 K3 N1 N2 N3 N4 ISO 513 CARBIDE END-MILLS Hardness/Rm ≤700 N/mm² 600÷1000 N/mm² ≤35 HRC ap x ae DxD DxD DxD DxD G2 Vc (m/min) 60÷80 40÷60 25÷35 70÷100 MDTA HF VH/UP D fz fz fz fz MEF (mm) (mm/z) (mm/z) (mm/z) (mm/z) ALU DRILLING 2 0.004 0.004 0.003 0.005 MEX/MH 3 0.006 0.005 0.005 0.008 UH/MH 4 0.008 0.007 0.006 0.011 5 0.011 0.009 0.008 0.014 6 0.014 0.011 0.010 0.018 8 0.018 0.015 0.014 0.023 10 0.021 0.018 0.016 0.027 12 0.025 0.021 0.018 0.032 < D3 mm: ap = 0.5D HSS END-MILLS CARBIDE BURRS 305
