HSS and HSS/Co drills 1693LS DIN1869/3 INFO LS type for deep holes. extra-long/3 CARBIDE DRILLS PU-HPU TA-4HTA P M K N S H SUH ALH H H HRC H 1st choice I suitable SUH MINI HL HSD C-SD-TA D(h8) D Tol. d l L PACKAGING EDP No. Stock 3.50 0/-0.018 3.5 180 265 1 P1693LS0350 h 4.00 0/-0.018 4 190 280 1 P1693LS0400 h 4.50 0/-0.018 4.5 200 295 1 P1693LS0450 h 5.00 0/-0.018 5 210 315 1 P1693LS0500 h 5.50 0/-0.018 5.5 225 330 1 P1693LS0550 h HSS 6.00 0/-0.018 6 225 330 1 P1693LS0600 h DRILLS 6.50 0/-0.022 6.5 235 350 1 P1693LS0650 h 7.00 0/-0.022 7 250 370 1 P1693LS0700 h LFTA 7.50 0/-0.022 7.5 250 370 1 P1693LS0750 h SUTAHSS-HSS/CO 8.00 0/-0.022 8 265 390 1 P1693LS0800 h 8.50 0/-0.022 8.5 265 390 1 P1693LS0850 h 9.00 0/-0.022 9 280 410 1 P1693LS0900 h 9.50 0/-0.022 9.5 280 410 1 P1693LS0950 h 10.00 0/-0.022 10 295 430 1 P1693LS1000 h 10.50 0/-0.027 10.5 295 430 1 P1693LS1050 h 11.00 0/-0.027 11 310 455 1 P1693LS1100 h CARBIDE 12.00 0/-0.027 12 330 480 1 P1693LS1200 h END-MILLS G2 MDTA HF VH/UP MEF ALU MEX/MH UH/MH HSS END-MILLS CARBIDE BURRS h stock standard f non-standard stock m stock exhaustion 263
