DRILLING Stock DRILLING (INDEXABLE TYPE) MVX (mm) *1 W DC L/D Order Number *2No.TLU LBX LPR OAL DCON DCSFMS S10 Insert Type F Clamp Screw Wrench 2 MVX1750X2F25 s 2 35 42 62 112 25 32 0.45 SOoX06 TPS25 TIP07F 3 MVX1750X3F25 s 2 52.5 59.5 79.5 129.5 25 32 0.45 SOoX06 TPS25 TIP07F 17.5 4 MVX1750X4F25 s 2 70 77 97 147 25 32 0.45 SOoX06 TPS25 TIP07F 5 MVX1750X5F25 s 2 87.5 94.5 114.5 164.5 25 32 0.45 SOoX06 TPS25 TIP07F 6 MVX1750X6F25 s 2 105 112 132 182 25 32 0.45 SOoX06 TPS25 TIP07F 2 MVX1800X2F25 s 2 36 43 63 113 25 32 0.4 SOoX06 TPS25 TIP07F 3 MVX1800X3F25 s 2 54 61 81 131 25 32 0.4 SOoX06 TPS25 TIP07F 18.0 4 MVX1800X4F25 s 2 72 79 99 149 25 32 0.4 SOoX06 TPS25 TIP07F 5 MVX1800X5F25 s 2 90 97 117 167 25 32 0.4 SOoX06 TPS25 TIP07F 6 MVX1800X6F25 s 2 108 115 135 185 25 32 0.4 SOoX06 TPS25 TIP07F 2 MVX1850X2F25 s 2 37 44 64 114 25 32 0.35 SOoX06 TPS25 TIP07F 3 MVX1850X3F25 s 2 55.5 62.5 82.5 132.5 25 32 0.35 SOoX06 TPS25 TIP07F 18.5 4 MVX1850X4F25 s 2 74 81 101 151 25 32 0.35 SOoX06 TPS25 TIP07F 5 MVX1850X5F25 s 2 92.5 99.5 119.5 169.5 25 32 0.35 SOoX06 TPS25 TIP07F 6 MVX1850X6F25 s 2 111 118 138 188 25 32 0.35 SOoX06 TPS25 TIP07F 2 MVX1900X2F25 s 2 38 45 65 115 25 32 0.3 SOoX06 TPS25 TIP07F 3 MVX1900X3F25 s 2 57 64 84 134 25 32 0.3 SOoX06 TPS25 TIP07F 19.0 4 MVX1900X4F25 s 2 76 83 103 153 25 32 0.3 SOoX06 TPS25 TIP07F 5 MVX1900X5F25 s 2 95 102 122 172 25 32 0.3 SOoX06 TPS25 TIP07F 6 MVX1900X6F25 s 2 114 121 141 191 25 32 0.3 SOoX06 TPS25 TIP07F 2 MVX1950X2F25 s 2 39 46 66 116 25 32 0.25 SOoX06 TPS25 TIP07F 3 MVX1950X3F25 s 2 58.5 65.5 85.5 135.5 25 32 0.25 SOoX06 TPS25 TIP07F 19.5 4 MVX1950X4F25 s 2 78 85 105 155 25 32 0.25 SOoX06 TPS25 TIP07F 5 MVX1950X5F25 s 2 97.5 104.5 124.5 174.5 25 32 0.25 SOoX06 TPS25 TIP07F 6 MVX1950X6F25 s 2 117 124 144 194 25 32 0.25 SOoX06 TPS25 TIP07F 2 MVX2000X2F25 s 2 40 47 67 117 25 32 0.6 SOoX07 TPS3 TIP10W 3 MVX2000X3F25 s 2 60 67 87 137 25 32 0.6 SOoX07 TPS3 TIP10W 20.0 4 MVX2000X4F25 s 2 80 87 107 157 25 32 0.6 SOoX07 TPS3 TIP10W 5 MVX2000X5F25 s 2 100 107 127 177 25 32 0.6 SOoX07 TPS3 TIP10W 6 MVX2000X6F25 s 2 120 127 147 197 25 32 0.6 SOoX07 TPS3 TIP10W 20.5 23 MVX2050X2F25 s 2 41 48 68 118 25MVX2050X3F25s261.568.588.5138.525320.55320.55SOoX07SOoX07TPS3TIP10WTPS3TIP10W 2 MVX2100X2F25 s 2 42 49 69 119 25 32 0.5 SOoX07 TPS3 TIP10W 3 MVX2100X3F25 s 2 63 70 90 140 25 32 0.5 SOoX07 TPS3 TIP10W 21.0 4 MVX2100X4F25 s 2 84 91 111 161 25 32 0.5 SOoX07 TPS3 TIP10W 5 MVX2100X5F25 s 2 105 112 132 182 25 32 0.5 SOoX07 TPS3 TIP10W 6 MVX2100X6F25 s 2 126 133 153 203 25 32 0.5 SOoX07 TPS3 TIP10W M 21.5 23 MVX2150X2F25 s 2 43 50 70 120 25MVX2150X3F25s264.571.591.5141.525320.45320.45SOoX07SOoX07TPS3TIP10WTPS3TIP10W 2 MVX2200X2F25 s 2 44 51 71 121 25 32 0.4 SOoX07 TPS3 TIP10W 3 MVX2200X3F25 s 2 66 73 93 143 25 32 0.4 SOoX07 TPS3 TIP10W 22.0 4 MVX2200X4F25 s 2 88 95 115 165 25 32 0.4 SOoX07 TPS3 TIP10W 5 MVX2200X5F25 s 2 110 117 137 187 25 32 0.4 SOoX07 TPS3 TIP10W 6 MVX2200X6F25 s 2 132 139 159 209 25 32 0.4 SOoX07 TPS3 TIP10W 22.5 23 MVX2250X2F25 s 2 45 52 72 122 25MVX2250X3F25s267.574.594.5144.525320.35320.35SOoX07SOoX07TPS3TIP10WTPS3TIP10W *1 Clamp Torque (lbf-in) : TPS25=8.9, TPS3=17.7 *2 Number of Teeth s : Stocked in Japan M182
