DRILLING VP15TF Type DRILLING (SOLID CARBIDE) MHS Drill Diameter DC Stock Metric Decimal Fraction Wire / Thread L/D LUOrder NumberLCF LH OAL LF PL DCON (mm) Letter size (inch) mm inch mm inch mm inch mm inch mm inch mm inch mm inch 3 s MHS0550L030B 17.4 .685 30.6 1.205 31.1 1.224 81.1 3.193 80 3.150 1.1 .043 6 .236 3 8 s MHS0550L060B 45.0 1.772 60.5 2.382 61.0 2.402 111.0 4.370 110 4.331 1.0 .039 6 .236 4 5.500 .2165 14 s MHS0550L090B 78.0 3.071 90.5 3.563 91.0 3.583 141.0 5.551 140 5.512 1.0 .039 6 .236 4 19 s MHS0550L120B 105.5 4.154 120.5 4.744 121.0 4.764 171.0 6.732 170 6.693 1.0 .039 6 .236 4 25 s MHS0550L150B 138.5 5.453 150.5 5.925 151.0 5.945 201.0 7.913 200 7.874 1.0 .039 6 .236 4 3 r MHS0560L030B 17.8 .701 31.2 1.228 31.2 1.228 81.2 3.197 80 3.150 1.2 .047 6 .236 3 8 r MHS0560L060B 45.8 1.803 61.0 2.402 61.0 2.402 111.0 4.370 110 4.331 1.0 .039 6 .236 4 5.600 .2205 2 14 r MHS0560L090B 79.4 3.126 91.0 3.583 91.0 3.583 141.0 5.551 140 5.512 1.0 .039 6 .236 4 19 r MHS0560L120B 107.4 4.228 121.0 4.764 121.0 4.764 171.0 6.732 170 6.693 1.0 .039 6 .236 4 24 r MHS0560L150B 135.4 5.331 151.0 5.945 151.0 5.945 201.0 7.913 200 7.874 1.0 .039 6 .236 4 3 r MHS0570L030B 18.1 .713 31.2 1.228 31.2 1.228 81.2 3.197 80 3.150 1.2 .047 6 .236 3 8 r MHS0570L060B 46.6 1.835 61.0 2.402 61.0 2.402 111.0 4.370 110 4.331 1.0 .039 6 .236 4 5.700 .2244 13 r MHS0570L090B 75.1 2.957 91.0 3.583 91.0 3.583 141.0 5.551 140 5.512 1.0 .039 6 .236 4 19 r MHS0570L120B 109.3 4.303 121.0 4.764 121.0 4.764 171.0 6.732 170 6.693 1.0 .039 6 .236 4 24 r MHS0570L150B 137.8 5.425 151.0 5.945 151.0 5.945 201.0 7.913 200 7.874 1.0 .039 6 .236 4 3 s MHS0580L030B 18.4 .724 31.2 1.228 31.2 1.228 81.2 3.197 80 3.150 1.2 .047 6 .236 3 8 s MHS0580L060B 47.5 1.870 61.1 2.406 61.1 2.406 111.1 4.374 110 4.331 1.1 .043 6 .236 4 5.800 .2283 1 13 s MHS0580L090B 76.5 3.012 91.1 3.587 91.1 3.587 141.1 5.555 140 5.512 1.1 .043 6 .236 4 18 s MHS0580L120B 105.5 4.154 121.1 4.768 121.1 4.768 171.1 6.736 170 6.693 1.1 .043 6 .236 4 23 s MHS0580L150B 134.5 5.295 151.1 5.949 151.1 5.949 201.1 7.917 200 7.874 1.1 .043 6 .236 4 3 r MHS0590L030B 18.7 .736 31.2 1.228 31.2 1.228 81.2 3.197 80 3.150 1.2 .047 6 .236 3 8 r MHS0590L060B 48.3 1.902 61.1 2.406 61.1 2.406 111.1 4.374 110 4.331 1.1 .043 6 .236 4 5.900 .2323 13 r MHS0590L090B 77.8 3.063 91.1 3.587 91.1 3.587 141.1 5.555 140 5.512 1.1 .043 6 .236 4 18 r MHS0590L120B 107.3 4.224 121.1 4.768 121.1 4.768 171.1 6.736 170 6.693 1.1 .043 6 .236 4 23 r MHS0590L150B 136.8 5.386 151.1 5.949 151.1 5.949 201.1 7.917 200 7.874 1.1 .043 6 .236 4 2 s MHS0600L030B 13.0 .512 31.2 1.228 31.2 1.228 81.2 3.197 80 3.150 1.2 .047 6 .236 3 7 s MHS0600L060B 43.1 1.697 61.1 2.406 61.1 2.406 111.1 4.374 110 4.331 1.1 .043 6 .236 4 6.000 .2362 M7x1.0 12 s MHS0600L090B 73.1 2.878 91.1 3.587 91.1 3.587 141.1 5.555 140 5.512 1.1 .043 6 .236 4 17 s MHS0600L120B 103.1 4.059 121.1 4.768 121.1 4.768 171.1 6.736 170 6.693 1.1 .043 6 .236 4 22 s MHS0600L150B 133.1 5.240 151.1 5.949 151.1 5.949 201.1 7.917 200 7.874 1.1 .043 6 .236 4 2 r MHS0610L030B 13.3 .524 29.8 1.173 31.3 1.232 81.3 3.201 80 3.150 1.3 .051 8 .315 3 7 r MHS0610L060B 43.8 1.724 59.6 2.346 61.1 2.406 111.1 4.374 110 4.331 1.1 .043 8 .315 4 6.100 .2402 12 r MHS0610L090B 74.3 2.925 89.6 3.528 91.1 3.587 141.1 5.555 140 5.512 1.1 .043 8 .315 4 17 r MHS0610L120B 104.8 4.126 119.6 4.709 121.1 4.768 171.1 6.736 170 6.693 1.1 .043 8 .315 4 22 r MHS0610L150B 135.3 5.327 149.6 5.890 151.1 5.949 201.1 7.917 200 7.874 1.1 .043 8 .315 4 2 r MHS0620L030B 13.5 .531 29.8 1.173 31.3 1.232 81.3 3.201 80 3.150 1.3 .051 8 .315 3 M 7 r MHS0620L060B 44.5 1.752 59.6 2.346 61.1 2.406 111.1 4.374 110 4.331 1.1 .043 8 .315 4 6.200 .2441 12 r MHS0620L090B 75.5 2.972 89.6 3.528 91.1 3.587 141.1 5.555 140 5.512 1.1 .043 8 .315 4 17 r MHS0620L120B 106.5 4.193 119.6 4.709 121.1 4.768 171.1 6.736 170 6.693 1.1 .043 8 .315 4 21 r MHS0620L150B 131.3 5.169 149.6 5.890 151.1 5.949 201.1 7.917 200 7.874 1.1 .043 8 .315 4 2 r MHS0630L030B 13.7 .539 29.8 1.173 31.3 1.232 81.3 3.201 80 3.150 1.3 .051 8 .315 3 7 r MHS0630L060B 45.2 1.780 59.7 2.350 61.2 2.409 111.2 4.378 110 4.331 1.2 .047 8 .315 4 6.300 .2480 12 r MHS0630L090B 76.7 3.020 89.7 3.531 91.2 3.591 141.2 5.559 140 5.512 1.2 .047 8 .315 4 16 r MHS0630L120B 101.9 4.012 119.7 4.713 121.2 4.772 171.2 6.740 170 6.693 1.2 .047 8 .315 4 21 r MHS0630L150B 133.4 5.252 149.7 5.894 151.2 5.953 201.2 7.921 200 7.874 1.2 .047 8 .315 4 Note 1) Please contact Mitsubishi Materials for any geometry that is not in the catalog (e.g. different dia. and length). s : Stocked in Japan r : Made to Order M116
