IC830 IC6025 IC8250 IC8250 IC8150 IC807 IC5005 IC907 IC807 IC907 ITS BORE 90° 45º 45º 45° SCMT-SM 75º Square Inserts with a 7° Positive Flank for Semi-Finishing IC=L D1 and Finish Turning on Soft Materials and Exotic Alloys 7°RE S Dimensions Tough 1  Hard RecommendedMachining Data ap f Designation L S RE D1 (mm) (mm/rev) SCMT 09T304-SM 9.52 3.97 0.40 4.40 • • • • 0.50-3.00 0.07-0.25 SCMT 09T308-SM 9.52 3.97 0.80 4.40 • • • • • • • 0.50-3.00 0.10-0.30 SCMT 120404-SM 12.70 4.76 0.40 5.50 • 0.50-3.50 0.10-0.25 SCMT 120408-SM 12.70 4.76 0.80 5.50 • • • • 1.00-4.00 0.10-0.30 For tools, see page: IHPR (408) 90° 45º 45º 45° SCMT-14 75º Square Inserts with a 7° Positive Flank for Semi-Finishing IC=L D1 and Finish Turning on Soft Materials and Exotic Alloys 7°RE S Dimensions Tough 1  Hard Recommended Machining Data ap f Designation L S RE D1 (mm) (mm/rev) SCMT 09T304-14 9.52 3.97 0.40 4.40 • • 1.00-3.50 0.12-0.30 SCMT 120404-14 12.70 4.76 0.40 5.50 • 1.00-4.00 0.12-0.30 For tools, see page: IHPR (408) 457
