Каталог Iscar инструментальная оснастка 2022 - страница 81

BT MAS-403 SS BD_2 CSI ER16-20 ER25-50 DCONNWS A 0.003 A AT3 Taper 58-60 HRc BT-ER DCONXWS DIN6499 ER Collet Chuckswith BT MAS-403 ADB BD BD G2.520,000 RPM Tapered Shanks THID U<1.0 gmmCRKSLB LBX LPR Designation SS CSI DCONNWS(3) DCONXWS(4) LPR LBX LB BD BD_2 THID CRKS CDI(5) kg BT30 ER16X 70 (1) 30 ER16 0.5 10.0 70.00 48.0 - 28.00 - M10 M12 0 0.47 BT30 ER16X100 (1) 30 ER16 0.5 10.0 100.00 73.0 - 28.00 - M10 M12 0 0.61 BT30 ER20X 70 (1) 30 ER20 1.0 13.0 70.00 48.0 - 34.00 - M12 M12 0 0.51 BT30 ER25X 60 (1) 30 ER25 1.0 16.0 60.00 38.0 - 42.00 - M16 M12 0 0.46 BT30 ER32X 60 (1) 30 ER32 2.0 20.0 60.00 38.0 - 50.00 - M18X1.5 M12 0 0.42 BT40 ER11X100 M 40 ER11 0.5 7.0 100.00 73.0 - 16.00 - M6 M16 0 1.06 BT40 ER16X 70 40 ER16 0.5 10.0 70.00 43.0 - 28.00 - M12 M16 0 1.06 BT40 ER16X100 40 ER16 0.5 10.0 100.00 73.0 - 28.00 - M12 M16 0 1.20 BT40 ER16X100 M 40 ER16 0.5 10.0 100.00 73.0 - 22.00 - M10 M16 0 1.16 BT40 ER16X150 40 ER16 0.5 10.0 150.00 123.0 86.00 28.00 40.00 M12 M16 0 1.56 BT40 ER16X200 (2) 40 ER16 0.5 10.0 200.00 173.0 110.00 28.00 40.00 M10 M16 0 1.84 BT40 ER20X 70 40 ER20 1.0 13.0 70.00 43.0 - 34.00 - M12 M16 0 1.07 BT40 ER20X100 40 ER20 1.0 13.0 100.00 73.0 - 34.00 - M12 M16 0 1.27 BT40 ER20X120 40 ER20 1.0 13.0 120.00 93.0 - 34.00 - M12 M16 0 1.39 BT40 ER20X150 40 ER20 1.0 13.0 150.00 123.0 - 34.00 - M12 M16 0 1.61 BT40 ER25X 60 40 ER25 1.0 13.0 60.00 33.0 - 42.00 - M16 M16 0 1.00 BT40 ER25X100 40 ER25 1.0 16.0 100.00 73.0 - 42.00 - M16 M16 0 1.40 BT40 ER25X150 40 ER25 1.0 16.0 150.00 123.0 - 42.00 - M16 M16 0 2.07 BT40 ER32X 60 40 ER32 2.0 20.0 60.00 33.0 - 50.00 - M22X1.5 M16 0 0.90 BT40 ER32X100 40 ER32 2.0 20.0 100.00 73.0 - 50.00 - M22X1.5 M16 0 1.45 BT40 ER32X120 40 ER32 2.0 20.0 120.00 93.0 - 50.00 - M22X1.5 M16 0 1.74 BT40 ER32X150 40 ER32 2.0 20.0 150.00 123.0 - 50.00 - M22X1.5 M16 0 2.19 BT40 ER32X200 (2) 40 ER32 2.0 20.0 200.00 173.0 113.00 50.00 57.00 M22X1.5 M16 0 3.02 BT40 ER40X 80 40 ER40 3.0 26.0 80.00 53.0 - 63.00 - M28X1.5 M16 0 1.33 BT40 ER40X100 40 ER40 3.0 26.0 100.00 73.0 - 63.00 - M28X1.5 M16 0 1.32 BT40 ER40X150 40 ER40 3.0 26.0 150.00 123.0 - 63.00 - M28X1.5 M16 0 2.03 BT40 ER50X 90 40 ER50 10.0 34.0 90.00 63.0 - 78.00 - M28X1.5 M16 0 1.27 BT50 ER16X100 50 ER16 0.5 10.0 100.00 62.0 - 28.00 - M12 M24 0 3.70 BT50 ER16X125 50 ER16 0.5 10.0 125.00 87.0 - 28.00 - M12 M24 0 3.94 BT50 ER16X150 50 ER16 0.5 10.0 150.00 112.0 - 28.00 - M12 M24 0 3.99 BT50 ER16X200 (2) 50 ER16 0.5 10.0 200.00 162.0 85.00 28.00 40.00 M10 M24 0 4.51 BT50 ER20X100 50 ER20 1.0 10.0 100.00 62.0 - 34.00 - M12 M24 0 3.81 BT50 ER20X125 50 ER20 1.0 13.0 125.00 87.0 - 34.00 - M12 M24 0 4.16 BT50 ER20X150 50 ER20 1.0 13.0 150.00 112.0 - 34.00 - M12 M24 0 4.06 BT50 ER20X200 (2) 50 ER20 1.0 13.0 200.00 162.0 85.00 34.00 50.00 M12 M24 0 5.04 BT50 ER25X100 50 ER25 1.0 16.0 100.00 62.0 - 42.00 - M16 M24 0 3.90 BT50 ER25X150 50 ER25 1.0 16.0 150.00 112.0 - 42.00 - M16 M24 0 4.31 BT50 ER25X200 (2) 50 ER25 1.0 16.0 200.00 162.0 87.00 42.00 55.00 M16 M24 0 5.29 BT50 ER32X100 50 ER32 2.0 20.0 100.00 62.0 - 50.00 - M22X1.5 M24 0 4.01 BT50 ER32X125 50 ER32 2.0 20.0 125.00 87.0 - 50.00 - M12 M24 0 4.24 BT50 ER32X150 50 ER32 2.0 20.0 150.00 112.0 - 50.00 - M22X1.5 M24 0 4.64 BT50 ER32X200 (2) 50 ER32 2.0 20.0 200.00 162.0 88.00 50.00 63.00 M22X1.5 M24 0 5.80 BT50 ER40X100 50 ER40 3.0 26.0 100.00 62.0 - 63.00 - M28X1.5 M24 0 4.03 BT50 ER40X150 50 ER40 3.0 26.0 150.00 112.0 - 63.00 - M28X1.5 M24 0 5.05 BT50 ER40X200 (2) 50 ER40 3.0 26.0 200.00 162.0 - 63.00 - M28X1.5 M24 0 6.23 BT50 ER50X150 50 ER50 10.0 34.0 150.00 112.0 - 78.00 - M36X1.5 M24 0 5.50 • B is the designation for coolant through flange. (1) AD TYPE (2) Balanced to G6.3/12, 000 RPM (3) Minimum diameter (4) Maximum diameter (1) 1 - Hole for data chip, 0 - Without hole for data chip 712-713 684-688 682-684 629
