THREADING Spare Parts C5 SIR-22090-22 AI22 SR 8-32-L5.8-A22 SR 8-32-L15-S22 T-20/5 C5 SIL-27105-16 AE16 SR 5-40-L6.8-A16 SR 5-40-L12.2-S16 T-10/5 C5 SIR-27105-16 AI16 SR 5-40-L6.8-A16 SR 5-40-L12.2-S16 T-10/5 C5 SIL-27105-22 AE22 SR 8-32-L5.8-A22 SR 8-32-L15-S22 T-20/5 C5 SIR-27105-22 AI22 SR 8-32-L5.8-A22 SR 8-32-L15-S22 T-20/5 C6 SIL-14070-16 AE16 SR 5-40-L6.8-A16 SR 5-40-L12.2-S16 T-10/5 C6 SIR-14070-16 AI16 SR 5-40-L6.8-A16 SR 5-40-L12.2-S16 T-10/5 C6 SIL-17075-16 AE16 SR 5-40-L6.8-A16 SR 5-40-L12.2-S16 T-10/5 C6 SIL-19075-22 AE22 SR 8-32-L5.8-A22 SR 8-32-L15-S22 T-20/5 C6 SIR-17075-16 AI16 SR 5-40-L6.8-A16 SR 5-40-L12.2-S16 T-10/5 C6 SIR-19075-22 AI22 SR 8-32-L5.8-A22 SR 8-32-L15-S22 T-20/5 C6 SIL-22090-16 AE16 SR 5-40-L6.8-A16 SR 5-40-L12.2-S16 T-10/5 C6 SIR-22090-16 AI16 SR 5-40-L6.8-A16 SR 5-40-L12.2-S16 T-10/5 C6 SIL-22090-22 AE22 SR 8-32-L5.8-A22 SR 8-32-L15-S22 T-20/5 C6 SIR-22090-22 AI22 SR 8-32-L5.8-A22 SR 8-32-L15-S22 T-20/5 C6 SIL-27105-16 AE16 SR 5-40-L6.8-A16 SR 5-40-L12.2-S16 T-10/5 C6 SIR-27105-16 AI16 SR 5-40-L6.8-A16 SR 5-40-L12.2-S16 T-10/5 C6 SIL-27105-22 AE22 SR 8-32-L5.8-A22 SR 8-32-L15-S22 T-20/5 C6 SIR-27105-22 AI22 SR 8-32-L5.8-A22 SR 8-32-L15-S22 T-20/5 MGSIR/L OHX/OHN Solid Carbide Bars for Internal Turning and Threading DMIN DCONMS WF LF Right-hand shown Designation DCONMS LF OHN(1) OHX(2) WF DMIN MGSIR/L 06-06 6.00 59.00 16.0 42.0 3.90 7.00 SR 14-552 T-6/5 MGSIR/L 08-06 8.00 72.00 20.0 56.0 5.00 9.20 SR 14-552 T-6/5 • In order to maintain high machining reliability, we strongly recommend replacing the clamping screw every 10 insert indexes (1) Minimum overhang in adjustment range (2) Maximum overhang in adjustment range For inserts, see pages: IR/L-55° (640) • IR/L-60° (645) • IR/L-BSPT (673) • IR/L-ISO (655) • IR/L-NPT (670) • IR/L-NPTF (672) • IR/L-UN (662) • IR/L-W (667) For holders, see pages: SBB (106) 706 ISCAR
