PART SERIES SERIES TTFIR/L PINATRETRSNEARLIEFSACE GROOVING AND FACE TURNING HOLDERS Dmin Tmax ØDmin F L ØDmax Dmax Coolant Seal dg7 H1 L1 Thread Designation InsertSeatSized(inch) H1(inch) F(inch) L(inch) L1(inch) Tmax(inch) Dmin(inch) Dmax(inch) TTFIL25.4-3T12-20-33 3 1.000 0.453 0.516 8.000 1.220 0.472 0.787 1.300 PTlaTFcIeL2h5o.l4d-3eTr12-26-39 3 1.000 0.453 0.516 8.000 1.220 0.472 1.024 1.535 TTFIL25.4-3T12-33-48 3 1.000 0.453 0.516 8.000 1.220 0.472 1.300 1.889 TTFIL25.4-3T12-42-60 3 1.000 0.453 0.516 8.000 1.220 0.472 1.650 2.362 TTFIL25.4-3T12-54-85 3 1.000 0.453 0.516 8.000 1.220 0.472 2.126 3.346 TTFIL25.4-3T12-79-150 3 1.000 0.453 0.516 8.000 1.220 0.472 3.110 5.905 TTFIR25.4-3T12-20-33 3 1.000 0.453 0.516 8.000 1.220 0.472 0.787 1.300 TTFIR25.4-3T12-26-39 3 1.000 0.453 0.516 8.000 1.220 0.472 1.024 1.535 TTFIR25.4-3T12-33-48 3 1.000 0.453 0.516 8.000 1.220 0.472 1.300 1.889 TTFIR25.4-3T12-42-60 3 1.000 0.453 0.516 8.000 1.220 0.472 1.650 2.362 TTFIR25.4-3T12-54-85 3 1.000 0.453 0.516 8.000 1.220 0.472 2.126 3.346 TTFIR25.4-3T12-79-150 3 1.000 0.453 0.516 8.000 1.220 0.472 3.110 5.905 TTFIL25.4-4T12-18-34 4 1.000 0.453 0.508 8.000 1.220 0.472 0.709 1.338 TTFIL25.4-4T12-26-42 4 1.000 0.453 0.508 8.000 1.220 0.472 1.024 1.653 TTFIL25.4-4T12-34-55 4 1.000 0.453 0.508 8.000 1.220 0.472 1.339 2.165 TTFIR25.4-4T12-18-34 4 1.000 0.453 0.508 8.000 1.220 0.472 0.709 1.338 TTFIR25.4-4T12-26-42 4 1.000 0.453 0.508 8.000 1.220 0.472 1.024 1.653 TTFIR25.4-4T12-34-55 4 1.000 0.453 0.508 8.000 1.220 0.472 1.339 2.165 TTFIL31.7-4T12-47-70 4 1.250 0.571 0.646 10.000 1.220 0.472 1.850 2.756 TTFIL31.7-4T12-62-100 4 1.250 0.571 0.646 10.000 1.220 0.472 2.441 3.937 TTFIL31.7-4T12-92-180 4 1.250 0.571 0.646 10.000 1.220 0.472 3.622 7.087 TTFIR31.7-4T12-47-70 4 1.250 0.571 0.646 10.000 1.220 0.472 1.850 2.756 TTFIR31.7-4T12-62-100 4 1.250 0.571 0.646 10.000 1.220 0.472 2.441 3.937 TTFIR31.7-4T12-92-180 4 1.250 0.571 0.646 10.000 1.220 0.472 3.622 7.087 276
