PART SERIES SERIES TCLNR/L PT-ATYRPTESEHROIELDS ER FOR EXTERNAL TURNING ACCEPTS NEGATIVE 80° RHOMBIC INSERTS H H F 95° B L1 L Designation H B L L1 F TCLNL12-33B 0.750 0.750 4.500 0.980 1.000 PTlaCcLNeRh1o2ld-3e3rB 0.750 0.750 4.500 0.980 1.000 TCLNL16-33D 1.000 1.000 6.000 0.980 1.250 TCLNR16-33D 1.000 1.000 6.000 0.980 1.250 TCLNL20-33D 1.250 1.250 6.000 0.980 1.375 TCLNR20-33D 1.250 1.250 6.000 0.980 1.375 HARDWARE HARDWARE hardware desc 1 hardware desc 2 hardware desc 3 hardware desc 4 hardware desc 5 hardware desc 6 hardware desc 7 Insert Reference Clamp Clamp Spring Seat Screw Seat Wrench Clamp Screw Seat CN_ _33_ DLM3-NX DSP3 SO40085I T15 DLS3 LSC32A SERIES TVJNR/L PART SERIES T-TYPE HOLDER FOR EXTERNAL TURNING ACCEPTS NEGATIVE 35° RHOMBIC INSERTS PART SERIES H H 44° max. F B 93° L1 L Designation H B L L1 F TVJNL12-2.53B 0.750 0.750 4.500 1.380 1.000 TVJNR12-2.53B 0.750 0.750 4.500 1.380 1.000 PTlaVcJeNhL1o6l-d2e.5r3D 1.000 1.000 6.000 1.690 1.250 TVJNR16-2.53D 1.000 1.000 6.000 1.690 1.250 TVJNL20-2.53D 1.250 1.250 6.000 1.970 1.500 TVJNR20-2.53D 1.250 1.250 6.000 1.970 1.500 HARDWARE HDWR hardware desc 1 hardware desc 2 hardware desc 3 hardware desc 4 hardware desc 5 hardware desc 6 hardware desc 7 Insert Reference Clamp Clamp Spring Seat Screw Seat Wrench Clamp Screw Clamp Screw Wrench Seat VN_ X2.53_ DLM2.5V-NX DSP4 SO40085I T15 DLS4 L-W3 MSVI2.522 218
