IN4005 IN4030 IN2505IN4035 IN2530 IN4005IN4015 IN4030 IN4035 HiQuadF - Series 15M1P, 5M_P, 5G_M Coolant Material BrinnellHardness SFM Feed per Insert Mild 1018-1045 125-425 2 1 3 NO 300-650 Steel Low Alloy 4140, 8620, 4340 .025-.115 2 1 3 NO 150-425 Med Alloy P20, S7, H13, O1, A2 300-700 2 3 1 3 NO Free Machining 303, 416 5 3 4 1 2 NO 300 Series 304, 310, 316 5 3 4 1 2 NO Stainless Steel 150-425 220-550 .025-.110 400 Series 410, 420, 15-5PH, 17-4 PH 5 3 4 1 2 YES PH Series 13-8 5 3 4 1 2 YES Hardened Steel ALL - 200-400 .030-.050 2 1 3 NO Titanium 6AL-4V - 90-200 .030-.060 5 3 4 1 2 YES Note: Feed and speed recommendations are starting operating parameters. They are only guidelines from which further optimization should take place. Operating parameters are influenced by many machining variables. These variables may cause for reductions in feeds and speed or dramatic increases. Additionally, DOC and WOC may need to be revised to optimize the tools performance. HiQuad Plungers - Series QHU, 5J1P Material BrinnellHardness SFM Feed per Insert Coolant Aluminum 6061 T6, 7075 T6, 2024 - 1500 - 8000 .004 - .010 1 Yes Gray 250 - 800 Cast Iron 150 - 250 .005 - .012 2 1 No Nodular 200 - 800 Low Carbon 1018, 8620 100 - 250 250 - 800 .004 - .012 High Carbon F-6180 250 - 400 200 - 700 Steel 2 1 No Alloyed Steel 4140, 4340 150 - 300 .005 - .012 250 - 700 Tool Steel A-6, D-1, D-2 Up to 300 300 Series, 304, 316 - 250 - 600 .004 - .008 May not be StainlessSteel 400 Series 15-5 PH Up to 320 300 - 700 .005 - .010 3 2 1 required athigh speeds 13-8 PH - 200 - 250 .004 - .008 Yes NickelAlloys Inconel, Hastelloy, Waspalloy - 75-120 .004 - .008 3 2 1 Yes Titanium 6AL-4V - 100 - 150 .004 - .008 3 2 1 Yes 96
