0 SERIES 1KJ1_ 0 DEGREE LEAD ENDMILL Shoulder Channel Ramp Corkscrew Facing Coolant D1 D2 ap L3 a L1 L2 D1 L1 L2 L3 D2 Ramp Angle Effective Number Extension Overall Projection Shank Using .031” R Insert ap Cutter Number Diameter of Inserts Length Length Length Size/Style Insert Series Cut Depth 1KJ1D-0601279R01 0.625 1 1.25 3.25 1.22 .625 W 4 9 TH_S06 .275 1KJ1D-0702084R01 0.725 2 2.00 4.00 1.80 .750 W 3.1 TH_S06 .275 1KJ1D-0701184R01 0.750 2 1.25 3.25 1.05 .750 W 3.1 TH_S06 .275 1KJ1D-0701784R01 0.750 2 1.75 3.75 1.55 .750 W 3.1 TH_S06 .275 1KJ1D-0703084R01 0.750 2 3.00 5.00 2.80 .750 W 3.1 TH_S06 .275 1KJ1D-0801784R01 0.875 2 1.75 3.75 1.75 .750 W 2.5 TH_S06 .275 1KJ1D-1001784R01 1.000 3 1.75 3.75 1.75 .750 W 2.15 TH_S06 .275 1KJ1D-1001780R01 1.000 3 1.75 4.00 1.55 1.00 W 2.15 TH_S06 .275 1KJ1D-1003780R01 1.000 3 3.75 6.00 3.375 1.00 W N/A TH_S06 .275 1KJ1D-1003784R01 1.000 3 3.75 6.00 3.55 .75 W N/A TH_S06 .275 1KJ1D-1201784R01 1.250 4 1.75 3.75 1.75 .750 W 1.5 TH_S06 .275 1KJ1D-1201780R01 1.250 5 1.75 4.00 1.75 1.00 W 1.5 TH_S06 .275 1KJ1D-1501784R01 1.500 5 1.75 3.75 1.75 .750 W 1.3 TH_S06 .275 1KJ1D-1501780R01 1.500 6 1.75 4.00 1.75 1.00 W 1.3 TH_S06 .275 1KJ1D-1502281R01 1.500 6 2.25 4.50 2.25 1.25 W 1.3 TH_S06 .275 1KJ1G-1201784R01 1.250 3 1.75 3.75 1.75 .750 W 2.3 TH_S10 .433 1KJ1G-1202281R01 1.250 2 2.25 4.50 2.05 1.25 W 2.3 TH_S10 .433 1KJ1G-1202281R02 1.250 3 2.25 4.50 2.05 1.25 W 2.3 TH_S10 .433 1KJ1G-1204281R01 1.250 3 4.25 6.50 4.05 1.25 W N/A TH_S10 .433 1KJ1G-1502281R01 1.500 3 2.25 4.50 2.20 1.25 W 1.8 TH_S10 .433 1KJ1G-1502281R02 1.500 4 2.25 4.50 2.20 1.25 W 1.8 TH_S10 .433 1KJ1G-1504281R01 1.500 3 4.25 6.50 4.25 1.25W N/A TH_S10 .433 1KJ1G-2002281R01 2.000 5 2.25 4.50 2.25 1.25 W 1.5 TH_S10 .433 1KJ1P-2002281R01 2.000 4 2.25 4.50 2.25 1.25 W 1.5 TH_S13 .590 Operating Guidelines on page 91-92. 16
