HSBNR/L Dimensions (mm) DESIGNATION R L h b l f Insert Lever Screw Shim Shim Pin Wrench HSBNR/L 4040 S3109 • • 40 40 250 35 SNM 1066 LCL 32-NX LCS 8 LSS 104 LSP 8 L-W 5 HSBNR/L 5050 T3109 • • 50 50 300 43 • Marked: Standard items INCH HOLDERS CAN BE PRODUCED AS SPECIALS. HSDNN Dimensions (mm) DESIGNATION h b l f Insert Lever Screw Shim Shim Pin Wrench HSDNN 4040 S3109 • 40 40 250 35 SNM 1066 LCL 32-NX LCS 8 LSS 104 LSP 8 L-W 5 HSDNN 5050 T3109 • 50 50 300 43 • Marked: Standard items INCH HOLDERS CAN BE PRODUCED AS SPECIALS. 151
