SK DIN 69871 ( ISO 7388-1) TOOL HOLDERS INTEGRAL DRILL CHUCK HOLDER DIN 69871 Form A • Radial run-out less than 0.05mm . • Wrench-Lock chucks incorporate wrench groove for additional tightening force. • Integral shank design provides for greater accuracy and safty. • Wrench included . Size(mm) Capacity (mm) Order No . Model 132-12-401 132-12-402 132-12-403 JT40-KPU08-80 JT40-KPU13-90 JT40-KPU16-105 SK40-A SK40-A SK40-A 0.5-8 1.0-13 3-16 132-12- 501 132-12-502 132-12-503 JT50-KPU08-80 JT50-KPU13-100 JT50-KPU16-105 SK 50-A SK50-A SK 50-A 0.5-8 1.0-13 3-16 Shank L Wrench 37.5 50.5 57 80 90 105 WCN20 WCN32 WCN32 37.5 50.5 57 80 100 105 WCN 20 WCN32 WCN32 SHELL END MILL ARBOR DIN 69871 Form A • For clamping shell end mill and milling cutter. 33 Standard G 6.3 15 , 000 RPM Order No. Model 131-07-401 131-07-402 131-07-403 131-07-404 131-07-405 131-07-406 131-07-407 131-07-408 JT40- XMB16-60 JT40-XMB16-120 JT40- XMB22-60 JT40-XMB22-120 JT40- XMB27-60 JT40-XMB27-120 JT40- XMB32-60 JT40- XMB40-60 SK40-A SK40-A SK40-A SK40-A SK40-A SK40-A SK40-A SK40-A 16 16 22 22 27 27 32 40 34 34 42 42 60 60 78 89 60 120 60 120 60 120 60 60 17 17 19 19 21 21 24 27 MS08030 MS08030 MS10030 MS10030 SXM27 SXM27 SXM32 SXM40 JC08017 JC08017 JC10021 JC10021 JC12023 JC12023 JC14020 KXM40 MS03008 MS03008 MS04010 MS04010 MS05016 MS05016 MS06020 MS08020 131-07-501 131-07- 502 131-07- 503 131-07- 504 131-07-505 131-07- 506 131-07- 507 131-07- 508 131-07- 509 JT50- XMB16-60 JT50-XMB16-120 JT50- XMB22-60 JT50-XMB22-120 JT50- XMB27-60 JT50- XMB27-90 JT50-XMB27-120 JT50- XMB32-75 JT50- XMB 40-75 SK50-A SK50-A SK50-A SK50-A SK50-A SK50-A SK50-A SK50-A SK50-A 16 16 22 22 27 27 27 32 40 34 34 42 42 60 60 60 78 89 60 120 60 120 60 90 120 75 75 17 17 19 19 21 21 21 24 27 MS08030 MS08030 MS10030 MS10030 SXM27 SXM27 SXM27 SXM32 SXM40 JC08017 JC08017 JC10021 JC 10021 JC12023 JC12023 JC12023 JC14020 KXM40 MS03008 MS03008 MS04010 MS04010 MS05016 MS05016 MS05016 MS06020 MS08020
